Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness

Name: Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness
Brand: HongTai
Price: 800.00 USD

$China Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness wholesale$ $China Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness wholesale$ $China Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness wholesale$ $China Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness wholesale$ $China Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness wholesale$ $China Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness wholesale$ $China Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness wholesale$ $China Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness wholesale$ $China Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness wholesale$ $China Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness wholesale$ $China Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness wholesale$ $China Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness wholesale$ $China Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness wholesale$

Place of Origin : Henan, China

Shape : Block

Material : Silicon Carbide (SiC)

SiO2 Content (%) : 0.6%

Al2O3 Content (%) : <12%

MgO Content (%) : interentional standard

CaO Content (%) : interentional standard

Refractoriness (Degree) : Common (1580°< Refractoriness< 1770°)

SiC Content (%) : >80%

Model Number : HT

Brand Name : HongTai

Product name : Silicon Nitride Bonded Silicon Carbide Plate

Raw material : Silicon Carbide Powder

Name : Silicon carbide plate

Color : Black

Size : Customized Size

Application : Industrial Furnaces

Certificate : ISO9001-2008

Bulk density(g/cm3) : 2.6 - 2.9 Gm/cc

Fe2O3 : 0.5% Max

Sample : Provide

Packaging Details : wooden pallet with paper each layer, wrapped with thick paper and PVC film outside.

Port : Tianjin, Qingdao, Lianyungang, Shanghai, Ningbo

Supply Ability : 3000 Ton/Tons per Month high alumina refractory brick

MOQ : 2 tons

Price : $800.00 - $2,000.00/tons

Contact Now

Product Description

$Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness$

Silicon carbide is a man-made mineral, it is a covalent bond compound, it is the existence of this bond, so that it has high strength, hardness. The shed board, push board, slide board, support, sagger, flame slide, etc. produced with silicon carbide as the main raw materials. With the inherent characteristics of silicon carbide, with the product load softening and wear resistance, fast heat conduction, oxidation resistance, high temperature strength, long service life and other characteristics. Our factory produces silicon carbide products of various specifications all year round, and there are various kinds of special silicon carbide bricks (arch bricks) against kiln and furnace openings. The product has good thermal performance, high thermal stability, no deformation, no softening, no expansion under high temperature for a long time, and can maintain the inherent high thermal conductivity of silicon carbide. The product is also characterized by wear resistance and erosion.

$Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness$

Silicon nitride bonded silicon carbide Plate

Silicon nitride bonded silicon carbide plate is a refractory product made by nitriding and firing using SiC and Si powder as raw materials. Its characteristic is Si3N4 as the binding phase. Si3N4 exists between SiC crystal grains as needle-like or fibrous crystals and is an important new refractory material. Using the principle of reaction sintering, the SiC green body containing silicon powder is sintered by the nitridation reaction, and the firing process is completed in a closed furnace with nitrogen gas and easy control. The temperature, pressure and atmosphere in the furnace must be strictly controlled. Main process parameters: nitriding gas pressure 0.02～0.04MPa, furnace atmosphere containing O2 less than 0.01%, final nitriding temperature 1350～1450℃, total nitriding time varies with product shape and size.

Features and Appliciation

Silicon nitride bonded silicon carbide bricks have good alkali corrosion resistance, molten cryolite wettability, oxidation resistance, wear resistance, high thermal conductivity, thermal shock resistance and extremely low electrical conductivity. Silicon nitride combined with silicon carbide bricks are mainly used as the lining of the lower furnace body of the blast furnace, which is more than twice as long as the use of traditional refractory materials. In addition, it can be used as the lining of aluminum reduction electrolyzers and ceramic kiln furniture, which can save energy, increase life It can also be used as a blast furnace tuyere water-cooled pipe sleeve brick because of its advantages such as environmental pollution

Specification

$Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness$

name			silicon nitride bonded silicon carbide bricks
Apparent porosity %			≤17
Bulk density g/cm3			≥2.65
Cold crushing strength Mpa			≥160
Modulus rapture at room temperature			≥45
Modulus rapture at 1400℃ temperature			≥45
Coefficient of thermal liner expansion			≤4.18
Thermal cunductivity w/(m·k) (350℃)			≥16
Refractoriness℃			1800
Refractoriness Under Load 0.2Mpa			1600
Max working temperature			1550
Composition %	SiC	≥72
		Si3N4	≥20
		Fe2O3	≤0.3

Packing & Delivery

$Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness$

Packaging Silicon carbide plate
1.on wooden pallets with plastic cover: wooden pallet size :930*930 or 1000*1000 mm,
2.Load weight of each pallet: 1.5-2.0 tons.

Shipping
1.Our packaging is as per customer’s request
2.Normal goods delivered by sea transport
3.Sample shipping by express
4.We will shipping and delivery goods timely, quality and quantity guaranteed, and also in accordance with the contract and customer's requirement completely.

Delivery:
15-30 days working day for large quantity. The shipment we will arrange as soon as possible. Of course, if it is a custom
products, the shipping time will delay.
Sample:
Usually by EMS, DHL, UPS, TNT, FedEx. Anyway you like. Bulk order: Usually by sea.
Payment:
It can be through T/T, L/C at sight. The specific terms determined according to the quantity of the goods, etc.
Your inquiry related to our product & price will be replied within 24 hours.
Export:
Our products have been exported to many countries: Australia, Chile, USA, Russia, UK, Indonesia, etc., good quality have be
approved by our clients.

$Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness$

Company Profile

$Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness$

Henan HongTai kiln refractory co., LTD. Main products are high alumina brick, clay brick, fused zirconium corundum brick, fireproof ball lightweight insulation brick, wear-resistant pouring material, corundum pouring material, low cement high strength pouring material, impermeable material, self-flowing material, plastic material, and various types of refractory materials.For different industries, the cement industry with anti-flaking high-alumina bricks, alkali resistant bricks, phosphate bricks;Boiler industry USES all kinds of brand wear-resisting brick, corundum brick, mullite brick and other finalizing materials.

Henan HongTai kiln refractory co., LTD. : "quality first, reputation first, customer first: it is our aim."Scientific management, strong technical force, perfect testing means, advanced technological equipment and stable product quality are the guarantee of quality service. Henan HongTai kiln refractories co., LTD sincerely hopes to cooperate with you hand in hand and in good faith.

Why Choose Us

$Customized Size Silicon Nitride Bonded Silicon Carbide Plate at Common Refractoriness$

1.Strong professional:
Our company has thirty years producing experience in refractory products. Our manager will supervise on a various refractories production materials, process control, quality supervision and package delivery, and ensure the products are 100% qualified.
2.Annual supply:
Our company has passed ISO 9001 quality management system certification and SGS certification. And the annual supply of shaped and unshaped refractory product is 28, 800-35, 000 tons.
3.Export experiences:
Now we have gained a global sales network reaching Russia, South Korea, Vietnam, Pakistan, Bulgaria, France, India, Egypt, Congo, Angola, South Africa etc.
4. Production equipment:
Production and testing equipment are new, complete and automated or semi- automated. Such modern facilities and equipment have provided the fine technical guarantee for the production and testing.
5. Testing equipment:
Our company's testing equipment as follows:
High Temperature RUL. Tester
Bulk Density Tester
The Pressure Tester
Refractoriness Tester

FAQ

1. How can you control your quality?
For each production processing, we have complete QC system for the chemical composition and Physical properties. After production,
all the goods will be tested, and The quality certificate will be shipped along with goods.
2. What's your delivery time?
It usually needs about 15 days- 30 days after receiving the deposit.
3.Do you have any experiences of export?
Yes,and Now we have gained a global sales network reaching Taiwan, Russia, Korea, Vietnam, Pakistan, Bulgaria, French, India,
Congo, Angola, South Africa, and so on.
4. Do you provide free samples?
Yes, we can provide a free sample for testing, If we have sample in stock, The quantity based on the material type, The buyer should bear all the shipping costs.
5. Can we visit your Company?
Yes, certainly. You are very welcome to China and we will be honored to have a customer and friend.
